Insulators with tongue caps

Insulator 3 kV Tongue/Tongue 3 sheds
3EGF018723

Material ID	Name	Material	Weight	Specified mechanical load (SML)	Maximum design tensile load (MDTL)
3EGF018723	Insulator 3 kV Tongue/Tongue 3 sheds	Composite	2,72 kg	140 kN	56 kN	PDF	Request

Material ID	Name	Nominal voltage	Creepage Path	Rated impulse withstand voltage	Power-frequency withstand voltage, wet	Arcing distance
3EGF018723	Insulator 3 kV Tongue/Tongue 3 sheds	3 kV	360 mm	120 kV	45 kV	173 mm	PDF	Request
